PGBD5 | HUABIO M1012-1 product information

product summary

company name :

HUABIO

product type :

antibody

product name :

PGBD5

catalog :

M1012-1

quantity :

100μl

price :

360.00 USD

clonality :

monoclonal

host :

mouse

conjugate :

nonconjugated

clone name :

7-F8-5

reactivity :

human, mouse, rat

application :

western blot, immunohistochemistry - paraffin section

more info or order :

HUABIO product webpage


image 1 :

Western blot analysis of PGBD5 on different lysates with Mouse anti-PGBD5 antibody (M1012-1) at 1/500 dilution. Lane 1: Human brain tissue lysate Lane 2: Mouse brain tissue lysate Lysates/proteins at 20 µg/Lane. Predicted band size: 58 kDa Observed band size: 55 kDa Exposure time: 2 minutes; 8% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (M1012-1) at 1/500 dilution was used in 5% NFDM/TBST at room temperature for 2 hours. Goat Anti-Mouse IgG - HRP Secondary Antibody (HA1006) at 1:150,000 dilution was used for 1 hour at room temperature.

image 2 :

Immunocytochemistry analysis of SH-SY5Y cells labeling PGBD5 with Mouse anti-PGBD5 antibody (M1012-1) at 1/100 dilution. Cells were fixed in 4% paraformaldehyde for 15 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-PGBD5 antibody (M1012-1) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI. beta Tubulin (ET1602-4, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594, HA1122) was used as the secondary antibody at 1/1,000 dilution.

image 3 :

Immunocytochemistry analysis of Neuro-2a cells labeling PGBD5 with Mouse anti-PGBD5 antibody (M1012-1) at 1/100 dilution. Cells were fixed in 4% paraformaldehyde for 15 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-PGBD5 antibody (M1012-1) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI. beta Tubulin (ET1602-4, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594, HA1122) was used as the secondary antibody at 1/1,000 dilution.

product information

SKU :

M1012-1

Target name :

PGBD5

Species reactivity :

Human,Mouse,Rat

Applications :

WB,IF-Cell,IHC-P

Conjugate :

Non-conjugated

Immunogen :

Synthetic peptide with Human PGBD5 aa 61-110 / 524.

Uniprot id :

Q8N414>SwissProt: Q8N414 Human;SwissProt: D3YZI9 Mouse;Entrez Gene: 292098 Rat

Host :

Mouse

Clone number :

7-F8-5

Isotype :

IgG1

Size :

100μl

List Price :

360.00 USD

Storage Buffer :

1*PBS (pH7.4), 0.2% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide.

Form :

Liquid

Storage Instruction :

Shipped at 4℃. Store at +4℃ short term (1-2 weeks). It is recommended to aliquot into single-use upon delivery. Store at -20℃ long term.

Purity :

Protein A affinity purified.

Product type :

Mouse monoclonal Antibody

Positive control :

Human brain tissue lysate, Mouse brain tissue lysate, SH-SY5Y, Neuro-2a, C6, human lung squamous cell carcinoma tissue, mouse hippocampus tissue, mouse cerebellum tissue, rat cerebellum tissue.

Molecular wt :

Predicted band size: 58 kDa

Subcellular location :

Nucleus

Concentration :

2 mg/mL.

Recommended dilutions :

WB: 1:500-1:2,000 ;IF-Cell: 1:100-1:1,000 ;IHC-P: 1:200-1:400

Pic img4 :

https://storage.huabio.cn/huabio/productImg/M1012-1_4.jpg

Pic legend4 :

Immunocytochemistry analysis of C6 cells labeling PGBD5 with Mouse anti-PGBD5 antibody (M1012-1) at 1/1,000 dilution. Cells were fixed in 4% paraformaldehyde for 15 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-PGBD5 antibody (M1012-1) at 1/1,000 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI. beta Tubulin (ET1602-4, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594, HA1122) was used as the secondary antibody at 1/1,000 dilution.

Pic img5 :

https://storage.huabio.cn/huabio/productImg/M1012-1_5.jpg

Pic legend5 :

Immunohistochemical analysis of paraffin-embedded human lung squamous cell carcinoma tissue with Mouse anti-PGBD5 antibody (M1012-1) at 1/400 dilution. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) (high pressure) for 2 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (M1012-1) at 1/400 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Pic img6 :

https://storage.huabio.cn/huabio/productImg/M1012-1_6.jpg

Pic legend6 :

Immunohistochemical analysis of paraffin-embedded mouse hippocampus tissue with Mouse anti-PGBD5 antibody (M1012-1) at 1/400 dilution. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) (high pressure) for 2 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (M1012-1) at 1/400 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Pic img7 :

https://storage.huabio.cn/huabio/productImg/M1012-1_7.jpg

Pic legend7 :

Immunohistochemical analysis of paraffin-embedded mouse cerebellum tissue with Mouse anti-PGBD5 antibody (M1012-1) at 1/200 dilution. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) (high pressure) for 2 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (M1012-1) at 1/200 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Pic img8 :

https://storage.huabio.cn/huabio/productImg/M1012-1_8.jpg

Pic legend8 :

Immunohistochemical analysis of paraffin-embedded rat cerebellum tissue with Mouse anti-PGBD5 antibody (M1012-1) at 1/200 dilution. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH 6.0) (high pressure) for 2 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (M1012-1) at 1/200 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
