CaV2.3 / CACNA1E | HUABIO HA723540 product information

product summary

company name :

HUABIO

product type :

antibody

product name :

CaV2.3 / CACNA1E

catalog :

HA723540

quantity :

100μl

price :

385.00 USD

clonality :

monoclonal

host :

domestic rabbit

conjugate :

nonconjugated

clone name :

PSH13-51

reactivity :

mouse, rat

application :

western blot, immunohistochemistry - paraffin section, immunohistochemistry - frozen section

more info or order :

HUABIO product webpage


image 1 :

Application: IHC-Fr Species: Mouse Site: hippocampus Sample: Frozen section Antibody concentration: 1/500 Antigen retrieval: Not required

image 2 :

Immunohistochemical analysis of paraffin-embedded mouse striatum tissue with Rabbit anti-CaV2.3 / CACNA1E antibody (HA723540) at 1/3,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA723540) at 1/3,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

image 3 :

Immunohistochemical analysis of paraffin-embedded mouse hippocampus tissue with Rabbit anti-CaV2.3 / CACNA1E antibody (HA723540) at 1/6,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA723540) at 1/6,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

product information

SKU :

HA723540

Target name :

CaV2.3 / CACNA1E

Species reactivity :

Mouse,Rat

Applications :

IHC-Fr,IHC-P,WB

Conjugate :

Non-conjugated

Immunogen :

Recombinant protein within human CACNA1E aa 1,964-2,313.

Uniprot id :

Q61290>SwissProt: Q61290 Mouse;SwissProt: Q07652 Rat

Host :

Rabbit

Clone number :

PSH13-51

Isotype :

IgG

Size :

100μl

List Price :

385.00 USD

Storage Buffer :

PBS (pH7.4), 0.1% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide.

Form :

Liquid

Storage Instruction :

Shipped at 4℃. Store at +4℃ short term (1-2 weeks). It is recommended to aliquot into single-use upon delivery. Store at -20℃ long term.

Purity :

Protein A affinity purified.

Product type :

Recombinant Rabbit monoclonal Antibody

Positive control :

Mouse striatum tissue, mouse hippocampus tissue, rat hippocampus tissue, Mouse brain tissue lysate, Mouse hippocampus tissue lysate, Rat brain tissue lysate.

Molecular wt :

Predicted band size: 262 kDa

Subcellular location :

Membrane

Concentration :

1 mg/mL.

Recommended dilutions :

IHC-Fr: 1:500 ;IHC-P: 1:3,000-1:6,000 ;WB: 1:5,000

Advanced Validation :

Relative expression (RE)

Pic img4 :

https://storage.huabio.cn/huabio/productImg/HA723540_4.jpg

Pic legend4 :

Immunohistochemical analysis of paraffin-embedded mouse kidney tissue (negative) with Rabbit anti-CaV2.3 / CACNA1E antibody (HA723540) at 1/3,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA723540) at 1/3,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Pic img5 :

https://storage.huabio.cn/huabio/productImg/HA723540_5.jpg

Pic legend5 :

Immunohistochemical analysis of paraffin-embedded rat hippocampus tissue with Rabbit anti-CaV2.3 / CACNA1E antibody (HA723540) at 1/6,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA723540) at 1/6,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Pic img6 :

https://storage.huabio.cn/huabio/productImg/HA723540_6.jpg

Pic legend6 :

Immunohistochemical analysis of paraffin-embedded rat kidney tissue (negative) with Rabbit anti-CaV2.3 / CACNA1E antibody (HA723540) at 1/3,000 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA723540) at 1/3,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Pic img7 :

https://storage.huabio.cn/huabio/productImg/HA723540_7.jpg

Pic legend7 :

Western blot analysis of CaV2.3 / CACNA1E on different lysates with Rabbit anti-CaV2.3 / CACNA1E antibody (HA723540) at 1/5,000 dilution. Lane 1: Mouse brain tissue lysate (no heat) Lane 2: Mouse hippocampus tissue lysate (no heat) Lane 3: Mouse lung tissue lysate (negative) (no heat) Lane 4: Rat brain tissue lysate (no heat) Notice: no heat means the lysate is not boiled. Lysates/proteins at 30 µg/Lane. Predicted band size: 262 kDa Observed band size: 257 kDa Exposure time: 46 seconds; ECL: K1801; 3-8% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA723540) at 1/5,000 dilution was used in primary antibody dilution (K1803) at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature.
