Cyclophilin F | HUABIO ET1705-7 product information

product summary

company name :

HUABIO

product type :

antibody

product name :

Cyclophilin F

catalog :

ET1705-7

quantity :

100μl

price :

385.00 USD

clonality :

monoclonal

host :

domestic rabbit

conjugate :

nonconjugated

clone name :

JM71-39

reactivity :

human, mouse, rat

application :

western blot, immunoprecipitation, flow cytometry, immunohistochemistry - paraffin section

more info or order :

HUABIO product webpage


image 1 :

Western blot analysis of Cyclophilin F on different lysates with Rabbit anti-Cyclophilin F antibody (ET1705-7) at 1/2,000 dilution. Lane 1: HEK-293 cell lysate (20 µg/Lane) Lane 2: HeLa cell lysate (20 µg/Lane) Lane 3: Mouse liver tissue lysate (40 µg/Lane) Lane 4: Rat liver tissue lysate (40 µg/Lane) Predicted band size: 22 kDa Observed band size: 17 kDa Exposure time: 59 seconds; ECL: K1801; 4-20% SDS-PAGE gel. Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (ET1705-7) at 1/2,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature.

image 2 :

Immunohistochemical analysis of paraffin-embedded human colon carcinoma tissue with Rabbit anti-Cyclophilin F antibody (ET1705-7) at 1/50 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1705-7) at 1/50 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

image 3 :

Immunohistochemical analysis of paraffin-embedded human breast carcinoma tissue with Rabbit anti-Cyclophilin F antibody (ET1705-7) at 1/50 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1705-7) at 1/50 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

product information

SKU :

ET1705-7

Target name :

Cyclophilin F

Species reactivity :

Human,Mouse,Rat

Applications :

WB,IHC-P,IP,FC

Conjugate :

Non-conjugated

Immunogen :

Synthetic peptide within Human Cyclophilin F aa 30-79 / 207.

Uniprot id :

P30405>SwissProt: P30405 Human;SwissProt: Q99KR7 Mouse;SwissProt: P29117 Rat

Host :

Rabbit

Clone number :

JM71-39

Isotype :

IgG

Size :

100μl

List Price :

385.00 USD

Storage Buffer :

1*TBS (pH7.4), 0.05% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide.

Form :

Liquid

Storage Instruction :

Shipped at 4℃. Store at +4℃ short term (1-2 weeks). It is recommended to aliquot into single-use upon delivery. Store at -20℃ long term.

Purity :

Protein A affinity purified.

Product type :

Recombinant Rabbit monoclonal Antibody

Positive control :

HEK-293 cell lysate, HeLa cell lysate, Mouse liver tissue lysate, Rat liver tissue lysate, human colon carcinoma tissue, human breast carcinoma tissue, mouse brain tissue, human colon tissue, HeLa.

Molecular wt :

Predicted band size: 22 kDa

Subcellular location :

Mitochondrion matrix.

Concentration :

1 mg/mL.

Recommended dilutions :

WB: 1:500-1:2,000 ;IHC-P: 1:50-1:400 ;IP: Use at an assay dependent concentration. ;FC: 1:1,000

Pic img4 :

https://storage.huabio.cn/huabio/productImg/ET1705-7_4.jpg

Pic legend4 :

Immunohistochemical analysis of paraffin-embedded mouse brain tissue with Rabbit anti-Cyclophilin F antibody (ET1705-7) at 1/50 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1705-7) at 1/50 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Pic img5 :

https://storage.huabio.cn/huabio/productImg/ET1705-7_5.jpg

Pic legend5 :

Immunohistochemical analysis of paraffin-embedded human colon tissue with Rabbit anti-Cyclophilin F antibody (ET1705-7) at 1/400 dilution. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ET1705-7) at 1/400 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Pic img6 :

https://storage.huabio.cn/huabio/productImg/ET1705-7_6.jpg

Pic legend6 :

Flow cytometric analysis of HeLa cells labeling Cyclophilin F. Cells were fixed and permeabilized. Then stained with the primary antibody (ET1705-7, 1/1,000) (red) compared with Rabbit IgG Isotype Control (green). After incubation of the primary antibody at +4℃ for an hour, the cells were stained with a iFluor™ 488 conjugate-Goat anti-Rabbit IgG Secondary antibody (HA1121) at 1/1,000 dilution for 30 minutes at +4℃. Unlabelled sample was used as a control (cells without incubation with primary antibody; black).
